plastic soft package testing instrument: location：index » analytical instruments » drk-d low temperature dilatometer (linear expansion coefficient tester) drk-d plastic (polymer material) expansion coefficient tester

drk-d low temperature dilatometer (linear expansion coefficient tester) drk-d plastic (polymer material) expansion coefficient tester

product brand： drick

detection project：

product video：

product documentation：

product enquiry：

counseling hotline：0531-85868997 0531-85760992

overview:

it is used to detect the low temperature expansion performance of solid inorganic, organic materials, polymers, polymer materials, metal/non-metal materials, rubber, plastics, metal products and other solid materials. applicable standards: astmd6962003, gb/t1036-2008 "determination of linear expansion coefficient of plastics - quartz dilatometer method", gb/t2572-2005 test method for average linear expansion coefficient of fiber reinforced plastics. the instrument can complete the sample linear variable, linear expansion coefficient, bulk expansion coefficient, rapid thermal expansion, softening temperature and their change curves.

product details

the main technical parameters:

1. experimental temperature range: -40-200℃, -30-200℃, 0-200℃. user optional.

2. the heating speed is automatically set by the computer program, the temperature control accuracy is 0.1 °c, and the heating and cooling speed is adjustable at 1-5 °c/min. equipped with precision (rapid) cooling-heating system (with a compressor imported from japan, with high power, fast cooling, and a rapid heating system).

3. the computer automatically calculates the expansion coefficient, volume expansion coefficient, linear expansion, and rapid thermal expansion.

4. automatic calculation of compensation coefficient and automatic compensation, or manual correction (online).

5. automatically record, store and print data, and print the temperature-expansion coefficient curve. the temperature interval can be set freely, the minimum interval is 0.1-1℃.

6. the deformation measurement adopts high-precision grating micrometer sensor, measuring range: ±12.7mm, resolution: 0.1um, precision 0.2um, automatic calibration range. the measurement range of the expansion value is large, and the adjustment range of the sample is increased.

7. sample range (2-15) × (2-15) × (20-150) mm, cylindrical or square.

8. the imported linear bearing is used for transmission to realize the frictionless transmission of the expansion value, and the transmission accuracy and repeatability are excellent.

9. system measurement error: ±0.1%.

11. power supply voltage: 220v±10﹪, 0.5kw.

10. equipped with a standard computer interface, which can be connected with a general-purpose computer. all test operations are completed by the computer interface, which is easy to operate and easy to learn and provides a complete set of software.
