pl6-s400 type sheet machine is a papermaking experimental equipment that copies fibers into square paper sheets with a size of 400mm×400mm. the vacuum formed by the rapid water discharge of the large-diameter valve is used for extraction and forming, and the vacuum pump is used to assist the extraction and forming, and the pulp is formed. there are two methods of stirring before: manual stirring and pneumatic stirring. it is suitable for the molding of various ultra-thin, ultra-thick and ultra-fine fibers. subsequent experiments were equipped with a pl8-c pattern press (hydraulic) to assist in pressing and squeezing water. optional pl7-c flat plate sample dryer to dry the paper samples.
technical parameter
1. specimen size: 400mm×400mm
2. copying cylinder volume: 64l
3. the power of the whole machine is 3.34kw and the voltage is 220v
4. vacuum pump power 1.5kw/220v vacuum degree: -0.092~-0.095mpa flow 260l/min
5. air compressor power 1.5kw/220v
6. self-priming pump power 370w/220v
