product details
l supports the measurement of moisture content in the full range including volumetric method and coulomb method to meet the measurement needs of different users of constant moisture and trace moisture;
l dot-matrix lcd display, key operation, simultaneous control or separate control by computer chinese software; real-time display of relevant test methods and test results;
l "conversational" operation steps to easily complete titration settings and process operations;
l pollution-free measurement and analysis process: anti-leakage device and waste bottle anti-suckback device; automatic liquid inlet, liquid discharge, kf reagent mixing and automatic cleaning functions, anti-titration cup solution overflow protection function; to prevent users from directly contacting kf reagents, to ensure the safety of measurement and use personnel and the environment;
l support pre-titration, automatic titration, manual titration, constant titration, kf titer determination and other titration modes to meet the analysis of different types of samples;
l supports a variety of burette types, and supports re-calibration of burette coefficients;
l users can choose mg, mg/l, %, ppm and other measurement result units as needed; the instrument supports glp specification, supports storage of 200 sets of constant and trace moisture measurement data; supports data storage, deletion, viewing, printing or output;
l with power-off protection function and kf reagent failure detection and reminder function;
l support rs232 serial printer to print measurement results;
l support firmware upgrade and software upgrade, allowing function expansion.
model technical parameters | drk-504 |
measuring range | volumetric method: (0.1~250.0) mg; coulometric method: 10μg～20mg |
measurement results | volumetric method: mg, mg/l, %, ppm four; coulometric method: μg, mg, %, ppm, mg/l, μg/ml. |
polarization current | 1µa±0.2µa；50µa±10µa； |
electrolytic current | coulomb method: 10 ma, 20 ma, 50 ma, 100 ma four current files. |
indication error | coulomb method: ±(5% verification point 3) μ3 |
repeatability | capacity method: ≤0.5% coulometric method: relative standard deviation (rsd) of the measured value at 100μg point ≤3% |
dimensions (mm), weight (kg) | 340×400×400(l×w×h); about 10 |
